Xinje DS2 series

51
7: speed (pulse)
03
Modbus station no. of COM2
-
1
1～255
●
All
04
Parameters of COM2
-
n.2206
n.0000
～
n.2209
●
All
05
Rotation direction
0: look at load side,
counterclockwise is forward.
1: look at load side, clockwise
is forward.
-
0
0, 1
●
2, 4, 6, 7
06
06.L: stop mode when servo
OFF or alarm. DS2 is inertia
stop. Keep inertia state after
stop.
-
2
0～2
●
All
06.H: stop mode when over
range 0~1: inertia stop. Keep
inertia state after stop.
2: deceleration stop. Change to
zero clamp state after stop.
Torque value: P4-06 urgent stop
torque
3: deceleration stop. Change to
inertia motion after stop.
Torque value: P4-06 urgent stop
torque.
-
2
0～3
●
All
07
T-REF distribution
0: undefined.
1: T-REF is external torque
-
0
0～3
○
3, 4, 5, 6,
7
