Xinje DS2 series Manual

43
 U-21 I/O signal status
Fig 1 Fig 2
In fig 1, input status is shown in LED4 and LED5; output status is shown in LED1 and
LED2. Fig 2 is the LED segment number.
 Input signal distribution
segment
instruction
segment
instruction
LED4_0
/SPD-A set internal speed
LED5_0
/S-ON servo signal
LED4_1
/SPD-B set internal speed
LED5_1
/P-CON ratio action command
LED4_2
/C-SEL control mode
selection
LED5_2
/P-OT ban positive rotation
LED4_3
/ZCLAMP zero clamp
LED5_3
/N-OT ban reverse rotation
LED4_5
/G-SEL gaining switch
LED5_5
/P-CL external torque limit at
forward rotation side
LED4_6
/CLR clean pulse
LED5_6
/N-CL external torque limit at
reverse rotation side
LED4_7
/CHGSTP change step
LED5_7
/SPD-D set internal speed
 Output signal distribution
segment
instruction
segment
instruction
LED1_0
Near （/NEAR）
LED2_0
Positioning end（/COIN）
LED1_1
Alarm output（/ALM）
LED2_1
Same speed dection
LED1 LED2 LED4 LED5
0
1
2
3
5
4
6
7
