Xinje DS2 series

31
 All types
1
5
(5-pin port)
Terminal
Name
Explanation
1
TXD
RS232 send
2
RXD
RS232 receive
3
GND
RS232 ground
Note: please use the cable offered by XINJE company.
 COM2
The COM2 position of each type:
Type
Port
COM
mode
Mark
DS2-2□P□-AS/AS6
DS2-4□P□-AS/AS6
A (CN1-14)
B (CN1-15)
RS485
This port cannot be used with
COM1 at the same time.
The parameters of COM2 can be set through P0-04:
Parameter
Function
Default setting
Range
P0-04.0
Baud rate
6
0～9
0：300
1：600
2：1200
3：2400
4：4800
5：9600
6：19200
7：38400
8：57600
9：115200
