Specifications
Specifications D - 3
D
Interface
Four USB 3.0 Ports (USB 3.1 Gen 1,
including 1 AC/DC Powered USB Port)
=======================================
One Type C USB 3.0 Port (USB 3.1 Gen 1)
OR One Thunderbolt™ 3 Port
=======================================
Two Mini DisplayPorts 1.3
One HDMI-Out (High-Definition
Multimedia Interface) Port (with HDCP)
One 2-in-1 Audio Jack
(Line-Out / S/PIDF optical output)
One Microphone-In Jack
One Headphone Jack
One RJ-45 LAN Jack
One DC-In Jack
*Note: The maximum amount of current supplied
by USB Type-C ports is 500 mA for USB2.0/900
mA for USB 3.1
Card Reader
Embedded Multi-In-1 Card Reader
- MMC/ RS MMC
- SD/ Mini SD / SDHC/ SDXC up to UHS-II
Note: Some of these cards require
adapters, which are usually supplied with
the cards.
Card Slots
Three M.2 Card Slots:
Slot WLAN
for M.2 2230 WLAN Combo
Module with PCIe*2 & USB Interfaces (A
Key)
Slot SSD1
for
M.2 2280
SSD
(Solid State
Drive) Card with SATA / PCIe Gen 3*4
Interface (M Key)
Slot SSD2
for
M.2 2280
SSD
(Solid State
Drive) Card with SATA / PCIe Gen 3*2
Interface (M Key)
Communication
Built-In 10/100/1000Mb Base-TX
Ethernet LAN
2.0M FHD PC Video Camera Module
Intel® Optane™ SSD Module Installa-
tion
Service personnel please note that In-
tel® Optane™ modules must be in-
stalled in the SSD1 slot.
Intel® Dual Band Wireless-AC 8265
(2*2 802.11 a/c) M.2 WLAN
+
Bluetooth
Combo M.2 2230 Module (
Factory Option
)
Intel® Dual Band Wireless-AC 3168
(1*1
802.11 ac) WLAN
+
Bluetooth Combo M.2
2230 Module (
Factory Option
)
Qualcomm
® Atheros Killer™ Wireless-
AC 1535 Dual Band (2*2 802.11 ac)
WLAN + Bluetooth 4.1 Combo
M.2 2230
Module
(Factory Option)
Wireless LAN AD
+ Bluetooth 4.1 Combo
M.2 2230 Card Module (
Factory Option
)
Power & Battery
Embedded 4 Cell Polymer Battery Pack
66WH
Full Range AC/DC Adapter - AC in 100 -
240V, 50 - 60Hz DC Output 19.5V, 11.8A
(230 Watts)
OR
Full Range AC/DC Adapter - AC in 100 -
240V, 50 - 60Hz DC Output 19V, 10.5A
(200 Watts)
To Next Page
