XO FLEX – Instructions for use Operation
42
Please note that the brake and the balance spring of the arm system should be adjusted by an XO
authorized service provider in accordance with the load of the hand instrument table.
Maximum load on hand instrument table attached to XO FLEX unit is 1.5 kg!
Exceeding the limit may compromise the balance of the instrument bridge and could
cause the bridge suspension arm to fail altogether exposing the patient to a risk.
3.21 SUCTION
Activate each suction hose individually by lifting it from the holder. When working solo, move the
suction hose holder forward to facilitate easy access to the suction hoses.
Figure 52 – Suction – (1) DUO position / (2) SOLO position
Relieve the suction hose by pressing it into the slot in the suction hose holder.
Figure 53 – Relieving the suction hose
3.22 CUSPIDOR AND CUP FILLER
Start the cuspidor flush manually with (1) – see Figure 54 – it will stop automatically after the preset
rinsing time.
Abort the cuspidor flush by activating (1) while rinsing.
