XO FLEX – Instructions for use Operation
35
Figure 37 – Attaching the irrigation tube to the instrument hose
IRRIGATION BAG
Insert the bag inlet cannula into the irrigation bag and hang the bag containing the irrigation liquid
from the knob at the bottom of the pump module – see Figure 38.
Figure 38 – Irrigation bag
IRRIGATION RESERVOIR
Place the reservoir containing the irrigation liquid into the holder below the pump – see Figure 39.
Figure 39 – Placing the reservoir
Using an appropriate sterile tool (e.g. a pair of scissors), cut the inlet cannula off the irrigation
tubing. Attach the irrigation tubing to the spear and place the spear in the reservoir.
See Figure 40.
