• Output frequency: current frequency supplied by the drive to the motor
• Left/Up/Down/Right: actual functions of the related push buttons
When parameter 105 MODE is set to Actuator, display shows the following information:
P02 ACTUAT.FRQ. D1
xx.x Hz
Actual Value Output Freq.
Left fct. Up fct. Down fct. Right fct.
where:
• ACTUAT.FRQ.1.: is the parameter description
• D1: is (for example) the selected source for the parameter, set by submenu 800
• XX.X: is the current parameter value
• Hz: is the dimension unit
• Actual value: is the input signal supplied by the selected transducer (set by submenu
400), expressed with the dimension unit set by parameter 405
• Output frequency: current frequency supplied by the drive to the motor
• Left/Up/Down/Right: actual functions of the related push buttons
P03 EFF.REQ.VAL.
The information shown on the display depends on the selection done in par. 105; for
more details, see P105 MODE (page 55)
When parameter 105 MODE is set to Controller, Cascade Relay, Cascade Serial or
Cascade Synchron, display shows the following information:
P03 EFF.REQ.VAL D1
xxx.xx bar
Actual Value Output Freq.
Left fct. Up fct. Down fct. Right fct.
where:
• EFF.REQ.VAL.: is the parameter description
• D1: is (for example) the selected source for the parameter, set by submenu 800
• XXX.XX: is the current parameter value
• bar: is the dimension unit set by parameter 405
• Actual value: is the input signal supplied by the selected transducer (set by submenu
400), expressed with the dimension unit set by parameter 405
• Output frequency: current frequency supplied by the drive to the motor
• Left/Up/Down/Right:actual functions of the related push buttons
When parameter 105 MODE is set to Actuator, P03 is not shown!
Parameter 03 EFF.REQ.VAL. shows the current required value that is calculated based on
parameter 505 ACT.VAL.INC., parameter 510 ACT.VAL.DEC. and parameter 330 LIFT
AMOUNT. If the required value is influenced by an offset signal (set by submenu 900),
then the current active required value is also shown in this window.
8 Programming
HVL 2.015-4.220 Installation, Operation, and Maintenance Manual 47

Xylem hydrovar Specifications

General

Frequency	50/60 Hz
Control type	Variable speed drive
Protection class	IP55
Communication protocols	Modbus
Relative Humidity	5% - 95% (non-condensing)
Altitude	Up to 1000 m without derating
Input voltage	200-690 V AC
Storage Temperature	-25°C to +70°C (-13°F to 158°F)
