P610 DELAY-TIME
2 sec
Actual Value Output Freq.
Left fct. Up fct. Down fct. Right fct.
Selects the delay time of the minimum threshold limit: it shuts off the HYDROVAR if the
actual value drops below P605 MIN.THRESH. or if a low-water protection (at terminals
X1/16–17) becomes open.
P615 ERROR RESET
G
P615 ERROR RESET
ON
Actual Value Output Freq.
Left fct. Up fct. Down fct. Right fct.
Selects automatic reset of errors; if a manual reset is selected, switch an external ON/OFF
contactor to the terminal X1/18-19. Possible setting are:
Setting Description
ON Allows an automatic restart five times when an error
occurs
Shuts off the unit after the fifth restart.
The internal counter is decreased by one after each
operating hour.
OFF Each error shown on the display.
Each error must be reset manually.
8.3.11 M700 OUTPUTS
MENU SCOPE
This submenu includes the following software parameters:
Analog output 1 and 2
Configuration of status relay 1 and 2
P705 ANALOG OUT.1
P705 ANALOG OUT.1
Output frequency
Actual Value Output Freq.
Left fct. Up fct. Down fct. Right fct.
Selects the first analog output, which is connected to terminal X3/3-4 on the Premim Card
(analogue output 0 – 10 V = 0 - 100%).
8 Programming
HVL 2.015-4.220 Installation, Operation, and Maintenance Manual 79
