P710 ANALOG OUT.2
P710 ANALOG OUT.2
Actual value
Actual Value Output Freq.
Left fct. Up fct. Down fct. Right fct.
Selects the second analog output, which is connected to terminal X3/5-6 on the Premim
Card (analog output 4 – 20 mA = 0 - 100%).
P715 CONF.REL.1
P715 CONF.REL.1
Running
Actual Value Output Freq.
Left fct. Up fct. Down fct. Right fct.
Selects the status relay 1 (X2/4 - 5 - 6). Possible settings are:
Setting Description Action if status = YES
Power HYDROVAR is connected to the power
supply.
Relay 1: X2/ 4 - 6 closed
Running The motor is running Relay 1: X2/ 4 - 6 closed
Errors An error is indicated on HYDROVAR
(including power failure).
Relay 1: X2/ 5 - 6 closed
Warnings A warning is indicated in the
HYDROVAR
Relay 1: X2/ 5 - 6 closed
StandBy The pump is released manually and
by external release, no error/warning
is indicated and the HYDROVAR does
not run.
Relay 1: X2/ 4 - 6 closed
Errorreset If the parameter P615 ERROR RESET
is activated and a warning occurs five
times - > Error - >
Relay 1: X2/ 4 - 6 closed
P720 CONF.REL.2
P720 CONF.REL.2
Errors
Actual Value Output Freq.
Left fct. Up fct. Down fct. Right fct.
Selects the status relay 2 (X2/1 - 2 - 3). Possible settings are:
Setting Description Action if status = YES
Power HYDROVAR is connected to the power
supply.
Relay 2: X2/ 1 - 3 closed
Running The motor is running Relay 2: X2/ 1 - 3 closed
Errors An error is indicated on HYDROVAR
(including power failure).
Relay 2: X2/ 2 - 3 closed
8 Programming
80 HVL 2.015-4.220 Installation, Operation, and Maintenance Manual

Xylem hydrovar Specifications

General

Frequency	50/60 Hz
Control type	Variable speed drive
Protection class	IP55
Communication protocols	Modbus
Relative Humidity	5% - 95% (non-condensing)
Altitude	Up to 1000 m without derating
Input voltage	200-690 V AC
Storage Temperature	-25°C to +70°C (-13°F to 158°F)
