Page #57 background imageLoading...
Page #57 background image
P62 JOG
This parameter deactivates the internal controller of HYDROVAR and changes to manual
mode. Display shows the following information:
P62 JOG
x.xx Hz
Actual Value Output Freq.
Left fct. Up fct. Down fct. Right fct.
Where:
JOG: is the parameter description
X.XX: is the current parameter value (0Hz - P245 MAX.FREQ.); at 0.0 Hz, the unit stops.
Actual value: is the input signal supplied by the selected transducer (set by submenu
400), expressed with the dimension unit set by parameter 405
Output frequency: current frequency supplied by the drive to the motor
Left/Up/Down/Right fct.: actual functions of the related push buttons
8.3.5 M100 BASIC SETTINGS
MENU SCOPE
This submenu includes the following software parameters:
Operation mode
Pump address
Password
Lock function
Display contrast
Display brightness
P105 MODE
By using this parameter, the user can select an operation mode.
P105 MODE
Controller
Actual Value Output Freq.
Left fct. Up fct. Down fct. Right fct.
where possible settings are:
MODE Operable unit(s)
Controller
(Default )
1 Hydrovar
Cascade Relay 1 Hydrovar and Premium Card
Cascade Serial More than one pump
Cascade Synchron All pumps operate on the same frequency
Actuator 1 Hydrovar
The Actuator mode is used if the HYDROVAR is a standard VFD with:
Fixed speed requirements or
An external speed signal is connected.
For more information, see Example: P105 ACTUATOR mode (page 102).
8 Programming
HVL 2.015-4.220 Installation, Operation, and Maintenance Manual 55
