XYZ Machine Tools SMX 5000 User Manual

96
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List - 3500 – Z Axis Drive Assembly (Figures 28a-c)
ITEM
PART NUMBER
DESCRIPTION
QTY
1
H-001
WORM GEAR
1
2
H-005
SCREW
20
3
H-026-A
ADJUSTING SCREW
3
4
H-045-10
KNEE
1
5
H-067-10
MACHINE BODY
1
6
H-077-3
BOLT
1
7
H-089-10
BALL SCREW
1
8
H-103
SCREW
20
9
H-109-8
ELEVATING FIXED PLATE(L)
1
10
H-110-8
ELEVATING FIXED PLATE(R)
1
11
H-111-8
ELEVATING FIXED PLATE FOR GIB
2
12
H-136
SCREW
18
13
H-140-10
FIXED HOLDER OF MOTOR
1
14
H-140-10B
FIXED HOLDER
1
15
16983-1
PULLEY - BALLSCREW
1
16
H-149-10
BALANCE WEIGHT
1
17
H-160-9
BEARING BRACKET
1
18
H-165-8
FIXED HOLDER OF COOLANT NOZZLE
1
19
H-167-10B
TOP COVER
1
20
H-168-10
FIXED HOLDER OF BALANCE WEIGHT
1
21
H-170-8
WASHER
1
22
H-254
OIL NETWORK
1
23
H-294-10
COOLANT NOZZLE
1
24
H-296
SCREW
2
25
H-297
SPRING PIN
1
26
H-331-8
ARM BRACKET
1
27
H-332-10
ARM COVER
1
28
H-418
SPRING WASHER
4
29
H-423-8
SPRING
2
30
H-443-5
MICRO SWITCH
2
31
H-444-5
ELECTRIC DEVICE BOX
1
32
H-445-5
CAP OF ELECTRIC DEVICE BOX
1
33
H-446-7
STOP BLOCK OF MACRO SWITCH
2
34
H-527-7
LOCKING BLOCK
2
35
H-547-7
KEY
1
36
H-583-7
SCREW
6
37
H-620-8
FIXED HOLDER OF MICRO SWITCH
1
38
H-621-8
FIXED HOLDER OF COOLANT NOZZLE
1
39
H-622-8
SCREW
4
40
H-637-8
MOTOR COVER
1
41
H-644-8
BALANCE WEIGHT
1
