XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
2.13 Machine Specifications
Model Name
2500
3500
4000
5000
Table Size
1245 x 229
1372 x 356
1474 x 356
1930 x 355
T-Slots (number x width)
3 x 15.9
4 x 15.9
4 x 15.9
4 x 15.9
Travel (X, Y, Z axis)
762 x 381 x
560
787 x 508 x
450
1016 x 596 x
520
1524 x 596 x
520
Quill Diameter
86
105
116
116
Maximum Quill Travel
127
127
127
127
Spindle Taper
R8
40 ISO
40 ISO
40 ISO
Spindle Speed Range
60 - 3500
40 - 5000
40 - 5000
40 - 5000
Spindle Centre to Column Face
457
520
610
610
Spindle Motor Power (HP)
3
5
7.5
7.5
Maximum Weight of Workpiece
600 Kg
600 Kg
850 Kg
850 Kg
Height of table from bottom of bed
864
835
956
956
Max spindle nose to table
597
620
620
620
rapid traverse X, Y, Z – standard
handwheels
3800
3800
3800
3800
Rapid traverse, X, Y, Z – electronic
handwheels
3800
6350
6350
6350
Overall Dimensions of Machine
(height includes 30mm levelling allowance)
587 x 1029 x
2480
3600 x 3143
x 2470
4405 x 3143
x 2690
5805 x 3143
x 2690
Shipping Weight
1900 Kg
2300 Kg
2750 Kg
3100 Kg
Electrical Power Requirements
20 Amp
25 Amp
25 Amp
25 Amp
2.14 ProtoTRAK SMX Control Hardware
 3-axis CNC, 3-axis DRO
 Precision ground ballscrews in the table, saddle and ram to ensure smooth accurate contours
without backlash
 Feedrate override of programmed feedrate and rapid
 Modular design simplifies service and maximizes uptime
 Control Pendant (part number 24000-8):
o 1.66 GHz PC-based processor
o 1 Gb of RAM
o 1 Gb flash drive
o 4 USB connectors
o 267 mm colour LCD for clear presentation of prompts, status information and part
graphics
 X, Y and Z Axes Motors (part number 24428-1):
o D.C. Servo Motors
o 560 in-oz. continuous torque
