XYZ Machine Tools SMX 5000 User Manual

101
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
ITEM
PART NUMBER
DESCRIPTION
QTY
47
J-273-3
RING
1
48
J-275-8
SOCKET SET SCREW
1
49
J-276-3
SCREW
2
50
J-278
SCREW
1
51
J-281
PIN Ø 5×12L
1
52
J-282
PIN
4
53
J-283-3
COMPRESSIVE SPRING
2
54
J-288
SNAP SPRING
1
55
J-289-3
QUILL HANDLE LOCK NUT
3
56
J-310
STEEL BALL
1
57
J-313
SCREW FOR J-055-3
1
58
J-319
SNAP RING
1
59
J-321-8
SAFETY CLUTCH SPRING
1
60
J-328-8
CLOCK SPRING
1
61
J-330
COMPRESSIVE SPRING
1
62
J-331
SNAP RING
1
63
J-333-3
PLASTIC BALL 1/2”
1
64
J-346-3
SPINDLE BEAPING “FAFNIR 2MM210WIDUL”
2
65
J-348-3
OIL GUIDE
1
66
J-349-3
BEARING 6208ZZ
1
67
J-355-8
HEX NUT
4
68
J-356
NUT
2
69
J-373
SPRING
1
70
F-61-8
QUILL PINION OVERLOAD CLUTCH LOCKNUT
1
71
M-36-8
PINION SHAFT HUB SLEEVE
1
72
M-54-8
PINION SHAFT HUB HANDLE
1
73
M-89
CLOCK SPRING STUD
1
74
732-8
DRAWBAR
1
75
894-3
KEY
1
76
897
OIL CUP
1
77
H-03-8
KNEE LEADSCREW FIXED NUT
1
78
H-03-8A
KNEE LEADSCREW ADJUSTING NUT
1
79
H-05
SCREW
20
80
H-50-8
KNEE
1
81
H-51-8
KNEE LEADSCREW
1
82
H-52
BEARING 6305Z (2 PCS/1 SET)
1
83
H-52-8
BEARING 6406(SKF BRAND)1 PC/1 SET
1
84
H-53
BEARING COVER
1
85
H-56
KEY
1
86
H-59-6
BEVEL GEAR
1
87
H-87-8
ELEVATING GIB
1
88
H-88
ADJUSTING SCREW
3
89
H-88-1
SET SCREW
3
90
H-93-8+94-8+95-8
ELEVATING LOCK
2
91
H-96-8
ALUMINUM PLATE (L)
4
92
H-103
SCREW
20
93
H-136
SCREW
18
94
H-271-8
MACHINE BODY
1
