XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List - 5000 - Z-Axis Drive Assembly (Figures 30a & b)
ITEM
PART NUMBER
DESCRIPTION
QTY
3
H-026-A
SCREW
3
4
H-026-B
SCREW
3
5
H-035-8
ALUMINUM PLATE
4
6
H-039-8
GIB
1
8
H-067-8
MACHINE BODY
9
H-077-3
SCREW
1
10
H-089-8B
BALL SCREW
1
11
H-109-12
GIB SEAT
1
12
H-110-12
GIB SEAT
1
13
H-111-9B
GIB
2
14
H-124-5
FIXED HOLDER OF MICRO SWITCH
1
15
H-139-8
ROLLER'S BRACKET ( R )
1
16
H-139-8A
ROLLER'S BRACKET ( L )
1
17
H-140-10
FIXED HOLDER OF MOTOR
1
18
H-140-10B
FIXED HOLDER
1
19
H-143-8C
BELT PULLEY
1
20
H-145-8
ROLLER
4
21
H-146-8
SPACER
4
22
H-147-8
ROLLER'S DRIVE SHAFT
4
23
H-148-8
SCREW
4
24
H-149-8A
BALANCE WEIGHT
1
25
H-160-9
BEARING BRACKET
1
26
H-165-8
FIXED HOLDER OF COOLANT NOZZLE
2
27
H-167-10B
TOP COVER
1
28
H-168-8
FIXED HOLDER OF BALANCE WEIGHT
1
29
H-170-8
WASHER
1
30
H-171-8
FIXED HOLDER OF MICRO SWITCH
1
31
H-293-10
VALVE
1
32
H-294-10
COOLANT NOZZLE
1
34
H-331-8
ARM BRACKET
1
35
H-332-14
ARM COVER
1
48
HT-067-14A
ELECTRIC CONTROL CABINET
1
49
HX-002-10
BEARING BUSHING
3
50
HX-007
BEARING COVER
1
51
HX-007-9
BEARING COVER
1
52
HX-028-10
FIXED SUPPORT OF DUST HELMET
2
53
HX-030-10
FIXED SUPPORT OF DUST HELMET
2
54
HX-037-8
EXPANSION PIPE
2
55
HX-046
STOP BLOCK OF LIMIT SWITCH
2
56
HY-043-14
ARM
1
59
NAME PLATE
1
60
24427
PULLEY (PART OF MOTOR 24428-1)
1
62
450-5M-15
BELT
1
63
90 DEG. TUBE
1
64
BEARING: TA3025
4
65
AB2562
BEARING: MM25BS62DH
2
67
AB6305ZZ
BEARING: 6305ZZ
1
