XYZ Machine Tools SMX 5000 User Manual

147
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
ITEM
P/N
DESCRIPTION
QTY
48
792-7
SPEED DISK
1
49
880
PLASTIC BALL
2
50
897
OIL CUP
1
51
898
OIL NOZZLE
1
52
936-7
FIXED COVER
1
53
HB-127-3
SPINDLE
1
54
HB-192-3
QUILL HOUSING
1
55
AB6009
BEARING 6009ZZ
1
56
AB6010
BEARING 6010ZZ
2
57
AB6210
BEARING 6210ZZ
2
58
AB6203
BEARING 6203ZZ
1
59
AB6303
BEARING 6303ZZ
1
60
ABE01760
BELT 5PK-760
2
61
ABE200600
BELT HTD-8M-600-32
1
62
AK0505015
KEY :5x5x15L
1
63
AK0505018
KEY :5x5x18L
1
64
AK0807040
MOTOR FIXED PULLEY KEY:8x7x60L
1
65
AKP1032020
PIN: Ø 3.2x20L
1
66
AKP10406
PIN: Ø 4x6L
1
67
AKP105020
PIN: Ø 5x20L
2
68
AKP10612
PIN: Ø 6x12L
1
69
ANI1238
NUT :1/2"-12NC
3
70
ANI13858
NUT :5/8"-18NF
1
71
ANI151614
NUT:5/16"-18NC
2
72
ASR110012
RING: Ø 1/2"
1
73
ARS112008
RING: Ø 8x1.2
1
74
ARS225080
RING: Ø 80x2.5
1
75
ASI314112
SCREW1/4"-20NC-1 1/2"L
4
76
ASI61412
SCREW:1/4"-20NC-1/2"L
4
77
ASI61414
SET SCREW:1/4"-20NC-1/4"L
1
78
ASI61434
SCREW:1/4"-20NC-3/4"L
11
79
ASI6316112
SET SCREW:3/16"-24NC-1 1/2"L
1
80
ASI6316316
SET SCREW:3/16"-24NC-3/16"L
2
81
ASI631634
SCREW:3/16"-24NC-3/4"L
3
82
ASI631638
SET SCREW:3/16"-24NC-3/8"L
1
83
ASI631658
SCREW:3/16"-24NC-5/8"L
2
84
ASI631678
SCREW:3/16-24NC-7/8"L
3
85
ASI612112
SCREW:1/2"-12NC-1 1/2"L
4
86
ASI651634
SCREW:5/16"-18NC-3/4"L
6
87
ASM306020
SCREW:M6x1.0-20L
6
88
ASI6141
SCREW:1/4"-20NC-1"L
6
89
AWIH0112
SPRING WASHER Ø ψ1/2"
3
90
AWIH0158
SPRING WASHER: Ø 5/8"
1
91
AWIH11014
SPINDLE WASHER: Ø 1/4"
1
92
AWMD0150
WASHER: Ø 50
1
93
AWMH0116
WAVE WASHER: Ø 16
1
94
AWMH0126
WAVE WASHER: Ø 26
1
i01292-1
