XYZ Machine Tools SMX 5000 User Manual

153
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List – SMX 4000 and 5000 Upper Head Assembly (Figures 63a & b)
ITEM
P/N
DESCRIPTION
QTY
1
210-3
GEAR
1
2
213-3
TIMING BELT PULLEY
1
3
231
BRAKE LOCK HANDLE
1
4
231-1
BOLT
1
5
232
BOLT
1
6
236
KEY
1
7
467-3
DRAWBAR WASHER
1
8
701-7
ALUMINUM CASE
1
9
702-8
GEAR BOX
1
10
703-7
BEARING HOUSING
1
11
704-3
SUPPORT PLATE
1
12
706-7A
PULLEY SHAFT CLUTCH
1
13
707-7B
MAIN SPINDLE FIXED PULLEY
1
14
708-10
SPINDLE BELT PULLEY
1
15
HB-198-10
MOTOR BELT PULLEY
1
16
714-7
KEY:8x7x70L
1
17
715-3
SPINDLE BRAKE
1
18
720
TRACTION SPRINGS
1
19
721-7
SLEVE
1
20
723-3
BEARING COVER
1
21
725-3
TOP COVER
1
22
726-3
BRAKE SHAFT
1
23
727
BRAKE CAMS
2
24
729
BRAKE SUPPORTER
1
25
731-3
BRAKE SHAFT SLEVE
1
26
732-8A
DRAWBAR
1
27
740-8
THREE-ADMISSION CLUTCH
1
28
741-3
SLIDING BEARING BOX
1
29
742-3
SPACER (SMALL)
1
30
743-3
SPACER (LARGE)
1
31
744
HIGH-LOW SPEED HUB
1
32
745-3
TOOTH CHANGE SHAFT
1
33
746
ROTATION PLATE
1
34
747
LOCKING NOZZLE
1
35
748
HIGH-LOW SPEED LEVER
1
36
749
SPRING
1
37
750
SPRING
3
38
752-3
DRIVE RING
1
39
753-8
BOLT
3
40
755
DRIVE RING
1
41
757
BEARING COVER
1
42
758-3
GEAR SHAFT
1
43
759
LOCKING SHAFT
1
44
760-8-1
INVERTER MOTOR 7.5 HP
1
45
764-3
LOCKING NUT
1
46
770-7
SPEED CHANGE BOX
1
47
786-7
NAME PLATE
1
