XYZ Machine Tools SMX 5000 User Manual

52
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List - SMX3500, 4000 and 5000 - Power Module (Figure 13)
Item
P/N
Title
Qty
1
24397
SHEETMETAL-SMX EURO 3500 POWER MODULE
1
2
25107-EURO
AC DRIVE- 7.5 HP V1000 -400V
1
4
22571-12
RAIL-DIN
1
5
23036
FUSE HOLDER-32 AMP-690V
7
6
22283-3/4-2-15
WIREWAY- TYPE G LIGHT GRAY
2
7
22392-3/4-15
COVER- WIREWAY- TYPE G
2
8
22891
RELAY-DUAL CHANNEL
1
9
22892-1
CONTACTOR - RELAY - 3 PHASE
1
10
22892-3
CONTACTOR - RELAY - 3 PHASE
1
11
22557
TERMINAL BLOCK-IEC-800V
10
13
23152-25
FUSE- 25A gG, 500V, 10x38 (F1, F2 and F3)
3
14
21258-3
TRANSFORMER-1.6kVA
1
15
23821
OVERLOAD-RELAY-12-18A
1
17
M5-0.8X10 10Z
SCREW-PH-PHIL-STL-ZINC
25
18
M6-1.0X12 10B
SCREW-PH-PHIL-STL-BO
8
19
22283-1-3-15
WIREWAY- TYPE G LIGHT GRAY
1
20
22392-1-15
COVER- WIREWAY- TYPE G
1
21
23152-2
FUSE- 2A, gG, 500V, 10x38 (F7))
1
22
24394
FILTER-EMC/FRI
1
23
23152-6
FUSE- 6A gG, 500V, 10x38 (F4 and F5)-
2
24
23152-16
FUSE- 16A gG, 500V, 10x38 (F6)
1
25
21953-10
TERMINAL- RING TONGUE
4
26
21953-14
TERMINAL- RING TONGUE
1
28
22406-BK-10G
WIRE- UL 83 THHN
7845
29
22406-BK-16G
WIRE- UL 83 THHN
9685
30
22406-GR-10G
WIRE- UL 83 THHN
1280
31
22406-GR-16G
WIRE- UL 83 THHN
790
32
24429-1
CABLE ASSY-350 SMX POWER CABLE
1
33
22684-5
CABLE ASSY - DOOR GUARD LOGIC
1
34
21455-2
CABLE ASSY-SX AUX SAFETY I/O
1
i24396
