XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
TERMINATION
ASSEMBLY CONNECTION
FUNCTION
TB1
COOLANT ENABLE - OUT/24VAC
COOLANT PORT (CABLE BREAK
OUT BOX)
TB2
COOLANT ENABLE - IN/24VAC
TB3
110 VAC - HI
POWER DRAWBAR / SPINDLE
BRAKE
TB4
110VAC - NEUTRAL
TB5
110 VAC - HI
SPINDLE CONTROL MODULE
TB6
110VAC - NEUTRAL
TB7
DOOR GUARD - OUT/24VAC
DOOR GUARD (24 VAC)
TB8
DOOR GUARD - IN/24VAC
TB9
DOOR GUARD - LOGIC/AUXIN9
DOOR GUARD (LOGIC)
TB10
DOOR GUARD - LOGIC/GND
i01351a
E-stop Safety Relay Wiring:
ALT WIRE COLOR
WIRE COLOR
EURO CONNECTOR
PIN NO.
SIGNAL
SAFETY RELAY
TERMINAL
BLACK
PINK
1
E STOP-SW1A
24
WHITE
RED
2
E STOP-SW2A
S13
RED
ORANGE
3
E STOP-SW3A
S23
WHITE/BLACK
BLUE
7
RESET-BT-A
X1
GREEN/BLACK
WHITE
9
E STOP-SW1B
23
ORANGE/BLACK
BLACK
10
E STOP-SW2B
S14
BLUE/BLACK
GREEN
11
E STOP-SW3B
S24
GREEN/WHITE
YELLOW
14
RESET-BT-B
X2
DRAIN WIRE
SHIELD
i01351b
