XYZ Machine Tools SMX 5000 User Manual

68
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List - SMX2500 - X-Axis Drive Assembly (Figure 17)
Item
P/N
Title
Qty
1
15621
DRIVE HOUSING
1
4
15624
FRONT COVER
1
5
15622
BACK COVER
1
6
15616
HANDWHEEL ASSY-MX
1
8
15612
HOUSING - BEARING
1
9
15885
RING-BEARING HOUSING
1
10
15638
STOP - X-AXIS (not shown on drawing)
1
11
15626
SEAL-BEARING HOUSING
1
12
16983-1
PULLEY-SOLID 44 TEETH W/O GUIDES
1
13
16452
NUT CLAMP-X ,Y, & Z AXIS
1
14
16350
FERRULE-SPROCKET
1
15
98481A090
KEY WOODRUFF #404-1/8 X 1/2
1
16
14772
SPACER - .100" THICK
5
19
425-5M-15
BELT - TIMING 5MM POWERGRIP
1
20
23930
BEARING-ANGULAR CONTACT- 7204 BECBP
SET
22
14772-2
SPACER - .020" THICK
2
23
14772-5
SPACER - .050" THICK
2
41
8-32X3/8 25B
SCREW-SHCS-STL-BO
6
42
5/16-18X1 25B
SCREW-SHCS-STL-BO
1
43
3/8-16X2 1/2 25B
SCREW-SHCS-STL-BO
4
44
M8-1.25X65 25B
SCREW-SHCS-STL-BO
4
45
M10-1.5X65 25B
SCREW-SHCS-STL-BO
4
46
1/4-20X1 24B
SCREW-HEX HD-STL-BO
7
47
8-32X3/8 20B
SCREW-RH-PHIL-STL-BO
3
48
10-32X3/4 25B
SCREW-SHCS-STL-BO
1
49
1/2-20 51Z
NUT-HEX JAM-STL-ZINC
2
51
M8 70P
WASHER-FLAT USS-STL-PLAIN
4
52
15759
WASHER-1/4 HARD BLK OX 1/8 THK
7
53
3/8 70P
WASHER-FLAT USS-STL-PLAIN
4
54
M10 70P
WASHER-FLAT USS-STL-PLAIN
4
55
1/2 73B
WASHER-SPLIT LOCK-STL-BO
1
56
1/2 70P
WASHER-FLAT USS-STL-PLAIN
1
57
22008
BEARING- 204KTT
1
i00911
Parts List - SMX2500 - X-Axis Electronic Handwheel Option (Figure 17)
Item
P/N
Description
Use As
Qty
57
22718
SPACER - 45 DEGREES X-AXIS
EA
1
58
21992
BUSHING-BALL SCREW
EA
1
59
14772
SPACER - .100” THICK
EA
1
60
M6-1.0X75 25B
SCREW – SHCS-STL-BO
EA
4
61
21946
ELECTRONIC HANDWHEEL
EA
1
