XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List – SMX 3500 - X-Axis Drive Assembly (figure 18)
No.
Part Number
Description
QTY
1
H-026-A
ADJUSTING SCREW
3
2
H-026-3
SCREW
2
3
H-028-3
GIB
1
4
H-031-3
GIB
4
5
H-032-3A
ALUMINUM PLATE
1
6
H-034-3
SADDLE
1
7
H-042-3
CHIP GUARD COVER PLATES(SMALL)
1
8
H-043-3
CHIP GUARD COVER PLATES(LARGE)
1
9
H-044-3
CHIP GUARD COVER PLATES(MIDDLE)
1
10
H-067-10A
MACHINE BASE
1
11
H-106-3
GIB SEAT
1
12
H-107-3
GIB SEAT
1
13
H-108-3
GIB
2
14
H-122-6
STOP BLOCK
2
15
H-124-7
MICRO SWITCH
1
16
H-124-7A
MICRO SWITCH COVER
1
17
H-134-3
PROTECTED COVER
1
18
HT-011-10A
RIGHT BEARING BRACKET
1
19
HT-012-2A
BEARING BRACKET
1
20
HT-012-2B
BEARING BRACKET
1
21
HT-015-3B
LONGITUDINAL FEED SCREW
1
22
HT-022-3
CROSS SCREW BRACKET
1
23
HT-029-10
TABLE
1
24
HT-032
RUBBER PLUNGER
8
25
HT-090-10
COVER
1
26
HT-149
BEARING BLOCK
1
27
HT-152
NUT
1
28
HT-162-10
BUSHING
1
29
HT-166
BUSHING
1
30
HT-181
OIL SEAL
1
31
24428-1
MOTOR
1
32
425-5M-15
BELT
1
33
16983-1
BELT PULLEY
1
35
AB6204ZZ
BEARING:6204ZZ
3
36
98481A090
KEY
1
37
AKP205030
PIN:φ5×30
2
38
ANI12012
NUT:1/2”-20NF
2
39
ASI631638
SCREW:3/16”-24NC-3/8”L
2
40
ASI231612
SCREW:3/16”-24NC-1/2”L
10
41
ASI61412
SCREW:1/4”-20NC-1/2”L
3
42
ASI61478
SCREW:1/4”-20NC-7/8”L
2
43
ASI6141
SCREW:1/4”-20NC-1”L
4
44
ASI6516134
SCREW:5/16”-18NC-1 3/4”L
2
45
ASI6381
SCREW:3/8”-16NC-1”L
12
46
ASI612112
SCREW:1/2”-12NC-1 1/2”L
8
47
ASI6121
SCREW:1/2”-12NC-1”L
2
48
15977
TRAY PAD
1
