XYZ Machine Tools SMX 5000 User Manual

73
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List - SMX2500 - Y-Axis Drive Assembly (Figure 19)
ITEM
P/N
DESCRIPTION
QTY
1
15966-3
BRACKET-Y AXIS MOTOR MOUNT
1
2
M10-1.5X60 25B
SCREW-SHCS-STL-BO
4
3
15968-2
LOWER COVER
1
4
15967-2
UPPER COVER
1
5
6-32X3/8 31Z
SCREW-PH-PHIL-EXT SEMS-STL-ZINC
8
7
1/2 70P
WASHER-FLAT USS-STL-PLAIN
1
8
30922
HANDLE FOLD-A-WAY
1
9
15616
HANDWHEEL ASSY-MX
1
10
1/2 75Z
WASHER-EXT TOOTH-STL-ZINC
1
11
1/2-20 51Z
NUT-HEX JAM-STL-ZINC
1
12
15614
TAB WASHER
1
13
14772
SPACER - .100" THICK
1
14
15980
BEARING HOUSING
1
15
20373
BEARING-ANGULAR CONTACT- 7204 BECBP
2
16
15885
RING-BEARING HOUSING
1
17
15626
SEAL-BEARING HOUSING
1
18
16350
FERRULE-SPROCKET
1
19
16983-1
PULLEY-SOLID 44 TEETH W/O GUIDES
1
20
16452
NUT CLAMP-X ,Y, & Z AXIS
1
21
565-5M-15
TIMING BELT
1
22
15627-1
DIAL HOLDER
1
27
10-32X3/4 25B
SCREW-SHCS-STL-BO
1
28
1/4-20X1 24B
SCREW-HEX HD-STL-BO
4
29
15759
WASHER-1/4 HARD BLK OX 1/8 THK
4
30
98481A090
KEY WOODRUFF #404-1/8 X 1/2
1
31
15836
DIAL NUT
1
32
M5-0.8X10 10Z
SCREW-PH-PHIL-STL-ZINC
2
33
21946
ELECTRONIC HANDWHEEL-X & Y AXIS
1
34
M6-1.0X75 25B
SCREW-SHCS-STL-BO
4
35
M6-1.0X25 25B
SCREW-PH-PHIL-STL-ZINC
4
36
21985
SPACER - 30 DEGREE Y-AXIS DRIVE ASSY
1
37
21992-1
BUSHING-BALLSCREW
1
38
1/4-20X5/8 26B
SCREW-FHCS-STL-BO
4
39
14772-2
SPACER-.020" THICK
1
40
21984
WAY COVER FRONT Y-AXIS DRIVE
1
41
25729
HANDLE REPLACEMENT KIT
1
15609-16
BALLSCREW - Y AXIS
1
i01132-Y-SX2
