XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List – SMX 4000– X Axis Drive Assembly (Figure 21)
ITEM
P/N
DESCRIPTION
QTY
1
H-026-A
ADJUSTING SCREW
3
2
H-026-3
SCREW
2
3
H-028-3
GIB
1
4
H-031-8
GIB
4
5
H-032-8
ALUMINUM PLATE
1
6
H-034-8
SADDLE
1
7
H-042-8
CHIP GUARD COVER PLATES(SMALL)
1
8
H-043-8
CHIP GUARD COVER PLATES(LARGE)
1
9
H-044-8
CHIP GUARD COVER PLATES(MIDDLE)
1
10
H-067-12A
MACHINE BASE
1
11
H-106-8
GIB SEAT
1
12
H-107-8
GIB SEAT
1
13
H-108-3
GIB
2
14
H-120-6
COVER
1
15
H-122-6
STOP BLOCK
2
16
H-124-7
MICRO SWITCH
1
17
H-124-7A
MICRO SWITCH COVER
1
18
H-134-8
PROTECTED COVER
2
19
HT-011-8B
RIGHT BEARING BRACKET
1
20
HT-012-8B
RIGHT BEARING BRACKET
1
21
HT-015-8C
LONGITUDINAL FEED SCREW
1
22
HT-022-8
FEED NUT BRACKET
1
23
HT-022-8B
CROSS SCREW BRACKET
1
24
HT-029-8
TABLE
1
25
HT-032
RUBBER PLUNGER
8
26
HT-040-7
BEARING COVER
1
27
HT-041-6
LOCKING SLEEVE
1
28
HT-042-8C
BELT PULLEY
1
29
HT-090-8
COVER
1
30
HT-098-8
COVER
1
31
HT-157-8
HANDWHEEL BRACKET
1
32
HT-166-8
BUSHING
1
33
HT-167
OIL SEAL
1
34
HT-181
OIL SEAL
1
35
HX-002
BUSHING
1
36
24428-1
MOTOR
1
37
615-5M-15
BELT
1
39
AB2562
BEARING:25BS62DH
2
40
AB6305ZZ
BEARING:6305ZZ
1
42
AK0505020
KEY:5x5x20
1
43
AKP205030
PIN:Ø5x30
6
