Parts List - SMX 2500 - Z-Axis Drive Assembly (Figure 27)
ITEM
P/N
TITLE
USE AS
QTY
1
16806-M
BALLSCREW ASSY- Z-AXIS
EA
1
2
PJ540015
BRACKET LOWER ELEVATING BALL SCREW
EA
1
3
2205E-2RS1TN9
BEARING SELF ALIGNMENT SKF
EA
1
4
16774
COVER - BEARING
EA
1
5
16795
MODIFIED BEVEL GEAR BS1236-2A
EA
1
6
M10-1.5X10 40B
SCREW-SOC SET-STL-BO-CUP
EA
1
7
16770
MODIFICATION OF 3 HP RAM PING JENG PART
EA
1
8
M6 73B
WASHER-SPLIT LOCK-STL-BO
EA
6
9
M6-1.0X25 25B
SCREW-SHCS-STL-BO
EA
6
10
7205-AVH
NILOS RING-7205
EA
1
11
16295-1
HOUSING- BEARING Z-AXIS
EA
1
12
16302
RING-BEARING HOUSING
EA
1
13
20374
BEARING-ANGULAR CONTACT-7205 BECBP
EA
2
14
16773
NUT CLAMP-Z AXIS
EA
1
15
10-32X3/4 25B
SCREW-SHCS-STL-BO
EA
1
16
16350
FERRULE-SPROCKET
EA
1
17
16983
PULLEY-SOLID 44 TEETH Z-AXIS
EA
1
18
N01
LOCKNUT
EA
1
19
W01
LOCKWASHER
EA
1
20
M8 73B
WASHER-SPLIT LOCK-STL-BO
EA
4
21
98481A090
KEY WOODRUFF #404-1/8 X 1/2
EA
1
22
M8-1.25X20 25B
SCREW-SHCS-STL-BO
EA
4
23
710-5M-15
BELT - TIMING
EA
1
24
21944
PLATE BALLSCREW SUPPORT - Z AXIS
EA
1
25
1/4-20X1 1/4 25B
SCREW-SHCS-STL-BO
EA
4
26
15759
WASHER-1/4 HARD BLK OX 1/8 THK
EA
4
27
23197
BRACKET-Z AXIS MOTOR-DPMS
EA
1
28
24421-8
MOTOR
EA
1
31
M10 73B
WASHER-SPLIT LOCK-STL-BO
EA
8
32
17030
LOUVRE- SPACER
EA
1
34
M10-1.5X45 25B
SCREW-SHCS-STL-BO
EA
8
35
M10 71B
WASHER-FLAT SAE-STL-BO
EA
4
i16790-XX
