Yamaha EF7200E - Fuel Cock; Ground (Earth) Terminal; Choke Lever (Except for EF5500 EFW)

– 11 –
7DF-106
1
22
Fuel cock lever
The fuel cock supplies fuel from the fuel tank to the
carburetor.
The fuel cock has two positions.
1 ON
With the lever in this position, fuel flows to the carbure-
tor. Normal using is done with the lever in this position.
2 OFF
With the lever in this position, fuel will not flow. Always
turn the lever to this position when the engine is not
running.
1
Ground (earth) terminal
Ground (earth) terminal connects the earth line for
prevention of electric shock.
When the electric device is earthed, always the gener-
ator must be earthed.
1 Ground (earth) terminal
