– 31 –
6. Add engine oil to the correct level.
NOTICE
Be sure no foreign material enters the crankcase.
5 Correct level
Recommended engine oil:
å YAMALUBE 4 (10W-40),
SAE 10W-30 or 10W-40
∫ SAE #30
ç SAE #20
∂ SAE 10W
Recommended engine oil grade:
API Service SE type or higher
Engine oil quantity:
1.1 L (1.16 US qt, 0.97 Imp qt)
7. Install the oil filler cap.
700-006a
5
0°C
A
YAMALUBE 4 (10W-40)
D
SAE 10W
C
SAE #20
B
SAE #30
32°F
25°C
80°F
5. Install a new gasket and the oil drain bolt, and
then tighten the bolt.
Oil drain bolt tightening torque:
27 Nm (2.7 m·kgf, 20 ft·lbf)
