Yamaha F100D - Installing the Water Pump and Shift Rod

LOWR
Lower unit
6-21
6D93G11
3. Install the propeller shaft housing assem-
bly
4
into the lower case, and then
install the straight key
5
, claw washer
6
, and ring nut
7
.
4. Tighten the ring nut to the specified
torque.
NOTE:
• To secure the ring nut, bend one tab
a
of
the claw washer into a slot in the ring nut.
• Bend all other tabs toward the propeller
shaft housing assembly.
Installing the water pump and shift
rod
1. Install the shift rod assembly
1
.
NOTE:
Install the shift rod assembly into the lower
case, turn it counterclockwise 90°
a
, and
then push it down
b
to connect it to the shift
slider
2
.
2. Install new oil seals into the oil seal hous-
ing as shown.
NOTE:
Install an oil seal halfway into the oil seal
housing, then the other oil seal.
Ring nut wrench 3
8
: 90890-06511
Ring nut wrench extension
9
:
90890-06513
T
R
.
.
Ring nut
7
:
103 N·m (10.3 kgf·m, 76.0 ft·lb)
Ball bearing attachment
3
:
90890-06655
Driver rod LS
4
: 90890-06606
Depth
c
:
4.0
±
0.5 mm (0.16
±
0.02 in)
S60C6430
A
LT
572
2
a
b
1
