Yamaha F100D - Steering arm

BRKT
Bracket unit
7-17
6D93G11
Steering arm
7
No. Part name Q’ty Remarks
1Nut 2
2 Steering hook 1
3 Stud bolt 2 M10
×
40 mm
4 Steering arm 1
5 Washer 1
6 Bushing 1
7O-ring 2
Not reusable
8 Bushing 2
9 Washer 1
10 Steering yoke 1
11 Damper 1
12 Circlip 1
A
A
A
11
7
6
5
4
8
12
10
9
7
8
1
2
3
T
R
.
.
20 N
·
m (2.0 kgf
·
m, 14.8 ft
·
Ib)
S6D87220
