Yamaha F100D - Shift rod

6D93G11
7-2
1
2
3
4
5
6
7
8
9
Shift rod
7
No. Part name Q’ty Remarks
1Bolt 1
2Spring 1
3Ball 1
4 Washer 1
5 Bushing 2
6Bolt 2 M6
×
25 mm
7Bracket 1
8 Shift rod 1
9Screw 2 ø4
×
16 mm
10 Plate 1
11 Shift position switch 1
12 Bolt 2 M6
×
50 mm
13 Bushing 1
14 Bracket 1
15 Cotter pin 1
Not reusable
16 Bushing 1
17 Lever 1
S6D87010
9
14
15
1
2
3
4
5
8
7
12
10
11
6
13
5
17
16
T
R
.
.
18 N
·
m (1.8 kgf
·
m, 13.3 ft
·
Ib)
T
R
.
.
1 N
·
m (0.1 kgf
·
m, 0.7 ft
·
Ib)
AA
AA
AA
AA
LT
572
LT
Special service tools / Shift rod
