6D93G11
8-4
1
2
3
4
5
6
7
8
9
Starboard view
1
Ignition coil
2
Cooling water temperature sensor
3
Starter motor
4
Junction box
5
Spark plug
S6D88020
1
5
2 3 4
Electrical components
