Yamaha F100D - Exhaust cover

POWR
Power unit
5-37
6D93G11
Exhaust cover
5
No. Part name Q’ty Remarks
1Gasket 1
Not reusable
2Screw 3 ø4
×
13 mm
3 Anode 3
4 Exhaust cover 1
5Gasket 1
Not reusable
6 Cooling water temperature sensor 1
7 Holder 1
8Bolt 2 M6
×
15 mm
9 Holder 1
10 Bolt 1 M6
×
10 mm
11 Gasket 1
Not reusable
12 Grommet 1
13 Pressure control valve 1
14 Spring 1
15 Cover 1
16 Bolt 3 M6
×
20 mm
17 Gasket 1
Not reusable
S6D85090
23
18
5
6
7
14
12
11
19
20
21
24
22
4
1
27
28
15
16
13
9
10
8
E
E
AA
LT
271
T
R
.
.
23 N
•
m (2.3 kgf
•
m, 17.0 ft
•
Ib)
17
2
3
2
2
3
3
25
26
T
R
.
.
49 N
·
m (4.9 kgf
·
m, 36.1 ft
·
Ib)
T
R
.
.
55 N
·
m (5.5 kgf
·
m, 40.6 ft
·
Ib)
29
30
T
R
.
.
1 6 N
·
m (0.6 kgf
·
m, 4.4 ft
·
lb)
2 12 N
·
m (1.2 kgf
·
m, 8.9 ft
·
lb)
LT
271
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
LT
271
T
R
.
.
18 N
·
m (1.8 kgf
·
m, 13.3 ft
·
Ib)
