Yamaha F100D - Page 163

6D93G11
7-8
1
2
3
4
5
6
7
8
9
7
No. Part name Q’ty Remarks
1Bolt 3 M8
×
45 mm
2 Upper mount 1
3Plate 1
4 Washer 2
5 Washer 2
6 Bolt 2 M12
×
194 mm
7Bolt 4 M8
×
40 mm
8 Muffler assembly 1
9Gasket 1
10 Drain bolt 1 M14
×
12 mm
11 Damper 1
12 Rubber seal 1
13 Gasket 1
Not reusable
14 Gasket 1
Not reusable
15 Screw 2 ø6
×
15 mm
16 Baffle plate 1
17 Grommet 1
S6D97020
AA
1
2
6
5
26
25
24
22
23
7
13
12
8
15
17
20
21
19
16
18
18
14
A
LT
572
LT
572
LT
572
LT
572
AA
A
AA
T
R
.
.
20 N
·
m (2.0 kgf
·
m, 14.8 ft
·
Ib)
T
R
.
.
28 N
·
m (2.8 kgf
·
m, 20.7 ft
·
Ib)
9
10
11
3
4
T
R
.
.
27 N
·
m (2.7 kgf
·
m, 20.0 ft
·
Ib)
LT
271
WR-No.2
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
Upper case
