Yamaha F100D - Page 165

6D93G11
7-10
1
2
3
4
5
6
7
8
9
7
No. Part name Q’ty Remarks
1 Exhaust guide 1
2Gasket 1
Not reusable
3 Dowel 2
4Gasket 1
Not reusable
5 Oil strainer 1
6 Collar 3
7Bolt 3 M6
×
25 mm
8Bolt 12 M6
×
25 mm
9 Oil pan 1
10 Gasket 1
Not reusable
11 Exhaust manifold 1
12 Bolt 4 M6
×
70 mm
13 Gasket 1
Not reusable
14 Gasket 2
Not reusable
15 Plate 1
16 Dowel 2
17 Bolt 6 M6
×
30 mm
S6D87060
17
19
18
20
21
22
14
15
12
8
3
3
9
7
4
13
10
11
1
2
5
6
16
16
AA
LT
572
LT
572
LT
572
LT
572
LT
572
LT
572
LT
572
LT
572
AA
T
R
.
.
11 N
·
m (1.1 kgf
·
m, 8.1 ft
·
Ib)
T
R
.
.
10 N
·
m (1.0 kgf
·
m, 7.4 ft
·
Ib)
Upper case
