Yamaha F100D - Page 175

6D93G11
7-20
1
2
3
4
5
6
7
8
9
7
No. Part name Q’ty Remarks
1 Swivel bracket 1
2 Tilt stop lever 1
3 Bushing 4
4 Distance collar 2
a
: 30.3–30.6 mm (1.19–1.20 in)
5Pin 2
6 Hook 1
7Bolt 1 M6
×
10 mm
8Spring 1
9 Tilt stop lever 1
10 Trim sensor 1
11 Screw 2 ø6
×
15 mm
12 Bolt 1 M6
×
10 mm
13 Clamp 2
14 Grease nipple 2
15 Ground lead 1
16 Pin 1
4
a
5 4 16 5
S6D87500
T
R
.
.
3 N
·
m (0.3 kgf
·
m, 2.2 ft
·
Ib)
AA
LT
572
LT
AA
AA
AA
1
3
2
10
14
13
12
13
9
3
11
15
14
3
4
5
8
3
6
7
4
16
Clamp brackets and swivel bracket
