Yamaha F100D - Page 187

6D93G11
7-32
1
2
3
4
5
6
7
8
9
7
No. Part name Q’ty Remarks
1 Manual release spring 1
2Ball 2
3Bracket 1
4Bolt 1 M3
×
5 mm
5Bolt 2 M5
×
6 mm
6 Washer 2
7O-ring 2
Not reusable
8 Adapter 2
9Spring 2
10 Ball 2
11 Gear 2
12 Drive shaft 1
13 Pin 2
14 Driven shaft 1
15 Ball 2
16 Pin 2
S6D87550
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
4
5
6
3
7
8
9
10
7
8
9
10
1
2
13
12
11
11
15
14
13
15
16
AA
AA
Gear pump
