Yamaha F100D - Page 237

6D93G11
9-16
1
2
3
4
5
6
7
8
9
Symptom: Shift mechanism of the forward gear and reverse gear does not operate properly.
Check the operation of the shift
rod.
Check the shift rod connection
between the lower case and
upper case and check the shift
rod for bends and wear.
Replace the shift rod.
Check the shift cables and links
of the remote control box.
Check the shift mechanism on
the bottom cowling (detent,
spring, ball).
Good operating
condition?
Good operating
condition?
Yes
Yes
Yes
No
No
No
Check the shift cable operation.
Disassemble the lower case,
and then check the operation of
the dog clutch.
Check the dogs of the forward
gear and reverse gear for
cracks and wear.
Yes
No
Check the dog clutch and slider
for cracks and wear.
Good operating
condition?
Good condition?
Bracket unit
