Electrical system
Í Fasten the wiring harness at the white
tape using the holder.
Î Fasten the wiring harnesses (to ignition
coil [#5]) and wiring harness (to cam posi-
tion sensor [STBD IN]) using the holder at
the white tape.
Ï Make sure that the bracket contacts the
stopper.
Ñ Fasten the knock sensor lead using the
holder. Make sure that the end of the cor-
rugated tube is positioned 30 mm (1.2 in)
from the holder.
Ò Route the knock sensor lead to the inside
of the wiring harness.
ËÈ
Í
É
Î
Ê
Ó
ÏÑÒ
Ô
Õ
×
Ì
To Next Page
