Yamaha F200B - Page 490

BRKT
Bracket unit
9-15
È X-transom model
No. Part name Q’ty Remarks
18 Upper mounting bolt 2 M14 × 190 mm
19 Cap 2
20 Bolt 1 M6 × 10 mm
21 Nipple 1
22 Plastic tie 2
23 Hose 1
24 Dowel 1 X-transom model
25 Adapter 1 X-transom model
26 Bolt 1 M6 × 25 mm/X-transom model
4
1
2
2
3
3
3
3
5
6
6
6
7
7
7
8
8
8
9
9
9
10
11
11
11
12
12
12
13
15
15
15
16
16
16
17
17
17
18
18
18
19
19
20
20
21
22
22
23
24
25
26
26
54 N m (5.4 kgf m, 39.8 ft lb)
72 N m (7.2 kgf m, 53.1 ft lb)
72 N m (7.2 kgf m, 53.1 ft lb)
4
5
14
È
