Yamaha F200C Service Manual

69J1D11
5-46
1
2
3
4
5
6
7
8
9
È
Tightening sequence
No. Part name Q’ty Remarks
1 Crankshaft 1
2 Cylinder block 1
3 Crankcase 1
4 Oil seal 1
Not reusable
5 Thrust bearing 2
6 Thrust bearing 1
7 Main bearing 4
8 Main bearing 4
9 Stud bolt 6 M8
×
95 mm
10 Bolt 8 M10
×
105 mm
11 Bolt 2 M8
×
95 mm
12 Bolt 13 M8
×
55 mm
13 O-ring 2
Not reusable
1.9
×
22.9 mm
14 O-ring 1
Not reusable
15 Bolt 2 M6
×
20 mm
16 Holder 2
17 Thermoswitch 2
18 Cover 2
19 Thermostat 2
20 Bolt 4 M6
×
25 mm
21 Clip 4
22 Cooling water hose 2
23 Oil seal 1
Not reusable
24 Oil seal 1
Not reusable
25 O-ring 2
Not reusable
26 Oil pump assembly 1
27 Gasket 1
Not reusable
28 Oil seal 1
Not reusable
29 Oil seal 2
Not reusable
30 Bolt 4 M6
×
40 mm
Cylinder block
