69J1D11
6-38
1
2
3
4
5
6
7
8
9
CAUTION:
• Do not press the propeller shaft threads
a
directly.
• Do not reuse the taper roller bearing,
always replace it with a new one.
6. Remove the oil seals and needle bear-
ing.
Checking the propeller shaft housing
1. Clean the propeller shaft housing using a
soft brush and cleaning solvent, and then
check it for cracks. Replace if necessary.
2. Check the teeth and dogs of the forward
gear for cracks or wear. Replace the
gear if necessary.
3. Check the bearings for pitting or rum-
bling. Replace if necessary.
Checking the propeller shaft
1. Check the propeller shaft for bends or
wear. Replace if necessary.
Oil seal installer
B
: YB-06168
Driver handle
C
: YB-06071
È
S69J6105
S69J6110
S69J6410
S69J6415
Propeller shaft housing (counter rotation model)
