Yamaha F200C Service Manual

69J1D11
7-36
1
2
3
4
5
6
7
8
9
3. Install the balls
7
, manual release spring
8
, and bracket
9
by installing the bolts
0
, then tightening them to the specified
torque.
4. Install the relief valve seal
A
and ball
B
into the gear housing 1
5
.
5. Install the filters
C
and gear pump
D
by
installing the bolts
E
, then tightening
them to the specified torque.
6. Install the manual valve
F
.
Assembling the tilt ram
1. Install the new dust seal
1
, O-rings
2
and
3
, and backup ring
4
into the tilt
cylinder end screw
5
.
T
R
.
.
Gear pump bracket bolt
0
:
7 N·m (0.7 kgf·m, 5.1 ft·lb)
T
R
.
.
Up-relief lock screw
a
height
(from the top of the gear housing):
1.8–2.0 mm (0.071–0.079 in)
Down-relief lock screw
b
depth
(from the top of the gear housing):
1.5–2.0 mm (0.059–0.079 in)
T
R
.
.
Gear pump bolt
E
:
7 N·m (0.7 kgf·m, 5.1 ft·lb)
Power trim and tilt unit

Yamaha F200C Specifications

General

Max Power Output	200 hp
Prop Shaft Horsepower	200 hp
Full Throttle RPM Range	5000-6000 rpm
Alternator Output at W.O.T.	50A
Compression Ratio	10.3:1
Exhaust	Through Propeller
Lubrication	Wet Sump
Ignition	TCI (Transistor Controlled Ignition)
Starting System	Electric
Gear Ratio	1.86:1
Gear Shift	F-N-R
C.A.R.B. Rating	3-Star
Steering	Remote
Displacement	2785 cc
Fuel Induction System	Electronic Fuel Injection (EFI)
Recommended Engine Oil	Yamalube 4M
Recommended Fuel Filter	Yamaha Fuel/Water Separating Filter (10 Micron)
Engine Type	4-Stroke, DOHC, 16-Valve In-Line 4
Bore x Stroke	96.0 x 96.2 mm
Fuel	Unleaded gasoline (87 octane minimum)
Cooling	Water-cooled, Thermostatic Control
