Yamaha F200C Service Manual

69J1D11
1-2
1
2
3
4
5
6
7
8
9
Symbols
The symbols below are designed to indicate the content of a chapter.
General information
Specifications
Periodic checks and adjustments
Fuel system
Power unit
Lower unit
Bracket unit
Electrical systems
Troubleshooting
GEN
INFO
SPEC
CHK
ADJ
FUEL
POWR
LOWR
BRKT
ELEC
TRBL
SHTG
– +
Symbols
1
to
6
indicate specific data.
1
Special tool
2
Specified oil or fluid
3
Specified engine speed
4
Specified tightening torque
5
Specified measurement
6
Specified electrical value
(resistance, voltage, electric current)
Symbols
7
to
A
in an exploded diagram indicate the grade of lubricant and the lubrication point.
7
Apply Yamaha 4-stroke motor oil
8
Apply water resistant grease (Yamaha grease A)
9
Apply molybdenum disulfide grease
0
Apply corrosion resistant grease
(Yamaha grease D)
A
Apply low temperature resistant grease
(Yamaha grease C)
Symbols
B
to
G
in an exploded diagram indicate the type of sealant or locking agent and the appli-
cation point.
B
Apply Gasket Maker
®
C
Apply Yamabond No. 4
D
Apply LOCTITE
®
No. 271 (Red)
E
Apply LOCTITE
®
No. 242 (Blue)
F
Apply LOCTITE
®
No. 572
G
Apply silicon sealant
123456
T
R
.
.
7890A
E
A M
D C
BCDEFG
GM
4
271
LT
242
LT
572
LT
SS
How to use this manual

Yamaha F200C Specifications
