Yamaha F200C Service Manual

69J1D11
6-6
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Shift rod 1
2 Oil seal 1
Not reusable
3 Oil seal housing 1
4 O-ring 1
Not reusable
3.1
×
70.6 mm
5Spring 1
6 Circlip 1
7Bolt 3 M6
×
20 mm
8 Seal 1
9 Woodruff key 1
10 Bolt 4 M8
×
45 mm
11 Cover 1
12 Seal 1
13 Water pump housing 1
14 O-ring 1
Not reusable
2.5
×
42 mm
15 Insert cartridge 1
16 O-ring 1
Not reusable
2.5
×
91.5 mm
17 Collar 1
18 Spacer 1
19 Washer 2
20 Wave washer 1
21 Impeller 1
22 Outer plate cartridge 1
23 Gasket 1
Not reusable
24 Dowel pin 2
Lower unit (regular rotation model)
