Yamaha F200C Service Manual

69J1D11
7-22
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Cylinder block 1
2 Reservoir 1
3Bolt 3 M8
×
20 mm
4 O-ring 1
Not reusable
1.9
×
12.6 mm
5 Reservoir cap 1 M12
×
10 mm
6 O-ring 1
Not reusable
7 Sheet 1
8Filter 1
9 Spacer 1
10 Bolt 3 M8
×
20 mm
11 O-ring 1
Not reusable
2.4
×
22.6 mm
12 Joint 1
13 O-ring 1
Not reusable
14 Manual valve 1
15 Circlip 1
16 Shaft 1
17 Circlip 1
18 Bushing 2
19 Pipe 1
20 Pipe 1
21 Yoke 1
22 Bolt 2 M5
×
12 mm
23 Washer 4
24 Wave washer 1
25 Washer 1
26 Bearing 2
27 Armature 1
28 Brush 4
29 Spring 4
30 Screw 2 M4
×
12 mm
31 Brush holder 1
32 Nut 2
33 Screw 2 M4
×
6 mm
34 O-ring 1
Not reusable
35 PTT motor base 1
36 Oil seal 1
Not reusable
37 PTT motor lead 1
Power trim and tilt unit
