Yamaha F200C Service Manual

69J1D11
4-12
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Starboard intake manifold 1
2 Throttle body #1 1
3 Throttle body #3 1
4 Throttle body #5 1
5 Starboard fuel rail 1
6 Port intake manifold 1
7 Throttle body #2 1
8 Throttle body #4 1
9 Throttle body #6 1
10 Port fuel rail 1
11 Pressure regulator 1
12 Bolt 18 M8
×
35 mm
13 Bolt 6 M6
×
10 mm
14 Gasket 6
Not reusable
15 Gasket 6
Not reusable
16 Collar 12
17 Spring 1
18 Washer 12
19 Bolt 12 M8
×
80 mm
20 Rubber seal 6
21 Fuel injector 6
22 Grommet 6
Not reusable
23 O-ring 6
Not reusable
2.1
×
11.8 mm
24 Collar 6
25 Bolt 6 M8
×
45 mm
26 O-ring 1
Not reusable
27 Screw 2 M6
×
12 mm
28 Cap 1
29 Fuel hose 1
30 Hose 6
31 Joint 1
32 Plastic tie 1
33 Joint 1
Intake manifold and high-pressure fuel line
