Yamaha RX-A4A - Page 24

24
RX-A4A
No. Main menu No. Sub-menu
U:
Universal system / 特殊端子系
U1 USB 1 USB FRONT 1 TRACK
2 USB FRONT 2 TRACK
N:
Network system / ネットワーク系
N1 NET 1 IP ADDRESS CHECK
2 MAC ADDRESS CHECK
3 LINE NOISE 100 MDI
4 LINE NOISE 100 MDIX
5 LINE NOISE 10 MDI
6 LINE NOISE 10 MDIX
7 LINK CHECK
8 EXT TEST
9 ETHER MAC ADDRESS
10 PING 1
11 PING 2
N2 WIFI 1 WIFI ON JIG01
2 WIFI ON JIG02
3 WIFI ON JIG03
4 WIFI ON JIG04
5 WIFI ON JIG05
6 WIFI ON JIG06
7 WIFI ON JIG07
8 WIFI ON JIG08
9 WIFI ON JIG09
10 WIFI ON JIG10
11 WIFI OFF
12 WIFI MAC ADDRESS
13 WIFI RF TEST
C:
Communication system / 通信・バスライン系
C1 ACCESS CHECK 1 ALL
2 BUS FLASH ROM
3 BUS FPGA
4 I2C
5 I2C2
6 DIR BUS
7 DSP BUS
8 EEPROM
9 JITTER
10 CEC CHECK
11 DSP I2S CHECK
12 DSP I2S CHECK
13 DSP I2S CHECK
14 DSP I2S CHECK
C2 NET CPU CHECK 1 ALL
2 APL (Apple) ID CHECK
C3 MCPU TO NCPU CHECK 1 SPI
2 MUTE H
3 MUTO L
C4 FRONT BUTTON CHECK 1 FRONT BUTTON
2 BUTTON DISPLAY
C5 DSP SPI CHECK 1 MAIN CPU
2 NET CPU
V:
Video system / ビデオ系
V1 ANALOG VIDEO CHECK 1 VIDEO INFORMATION
V2 DIGITAL VIDEO CHECK 1 HDMI REPEAT
2 HDMI SCALING
3 INVALID ITEM
(Not for service / サービスでは使用しません )
4 INVALID ITEM
(Not for service / サービスでは使用しません )
5 INVALID ITEM
(Not for service / サービスでは使用しません )
6 GUI-VIDEO OUT
No. Main menu No. Sub-menu
R:
Radio system / TUNER・衛星放送系
R1 TUNER / DAB+ 1 SIGNAL QUALITY (A, B, G, F models)
2 DAB MODULE VERSION (A, B, G, F models)
3 FM
4 AM
T:
Troubleshooting Information / サービス・設計用故障解析情報
T1 POWER 1 OPERATING TIME
2 POWER-RELAY ON
3 POWER AMP B
4 OUTPUT LEVEL
5 POWER OFF TIME-OUT
6 CPU OPERATION TIME
7 RESET START NUMBER
8 PROTECTION LOCK
T2 USAGE ENVIRONMENT 1 MAIN ZONE HIGHEST VOLUME
2 ZONE 2 HIGHEST VOLUME
3 INVALID ITEM
(Not for service / サービスでは使用しません )
4 THM HIGHEST TEMPERATURE
5 EEPROM ERROR
T3 EXTERNAL EVENT 1 HISTORY 1
2 HISTORY 2
3 HISTORY 3
4 HISTORY 4
5 HISTORY 5
6 HISTORY 6
7 HISTORY 7
8 HISTORY 8
