Yamaha RX-A4A - SPECIFICATIONS

6
RX-A4A
n
SPECIFICATIONS
n
Audio Section
Rated Output Power
– 1 channel driven –
(1 kHz, 0.9% THD, 8ohms)
FRONT L/R ............................................................................. 135W
CENTER ................................................................................. 135W
SURROUND L/R ..................................................................... 135W
SURROUND BACK L/R .......................................................... 135W
(1 kHz, 0.9% THD, 6ohms)
FRONT L/R ............................................................................. 140W
CENTER ................................................................................. 140W
SURROUND L/R ..................................................................... 140W
SURROUND BACK L/R .......................................................... 140W
(1 kHz, 0.9% THD, 4ohms)
FRONT L/R ............................................................................. 170W
– 2 channels driven –
(20 Hz to 20 kHz, 0.06% THD,
8ohms)
FRONT L/R ........................................................................ 110W/ch
CENTER ................................................................................. 110W
SURROUND L/R ................................................................ 110W/ch
SURROUND BACK L/R ..................................................... 110W/ch
(1 kHz, 0.9% THD, 8ohms)
FRONT L/R ........................................................................ 120W/ch
CENTER ................................................................................. 120W
SURROUND L/R ................................................................
120
W/ch
SURROUND BACK L/R .....................................................
120
W/ch
Maximum Effective Output Power
(1 channel driven)
(1 kHz, 10% THD 8 ohms)
FRONT L/R ............................................................................. 165W
CENTER ................................................................................. 165W
SURROUND L/R ..................................................................... 165W
SURROUND BACK L/R .......................................................... 165W
(1 kHz, 10% THD 6 ohms)
FRONT L/R ............................................................................. 170W
CENTER ................................................................................. 170W
SURROUND L/R ..................................................................... 170W
SURROUND BACK L/R .......................................................... 170W
Damping Factor
(1kHz, 8ohms)
FRONT L/R ....................................................................... 120 or more
Input Sensitivity/Input Impedance
(1kHz, Rated Power Output)
PHONO (MM) ........................................................3.7mV / 47 k-ohms
AUDIO 2 etc. ........................................................220 mV / 47 k-ohms
Rated Output Level/Output Impedance
PRE OUT
1kHz (except SUBWOOFER) ................................1.0V / 470ohms
50Hz SUBWOOFER ..............................................1.0V / 470ohms
ZONE OUT. ...........................................................
470mV / 470ohms
Maximum Input Signal
(1kHz, 0.5% THD)
PHONO (MM) ............................................................................ 45mV
AUDIO 2 etc.. .............................................................................. 2.4V
Maximum Output Level
PRE OUT
FRONT L/R etc. ........................................................................ 2.0V
SUBWOOFER ........................................................................... 6.5V
Headphone Impedance
................................................................................. 16ohms or more
Frequency Response
(10Hz to 100kHz)
AUDIO 2 etc. (PURE DIRECT) ............................................ +0 / -3dB
RIAA Equalization Deviation
(20Hz to 20kHz)
PHONO (MM) .................................................................... 0 ± 0.5dB
Total Harmonic Distortion
(1kHz 1V)
PHONO (MM) (PURE DIRECT) to PRE OUT ..................0.04% or less
(20 Hz to 20kHz, 55W, 8 ohms)
AUDIO 2 etc. (PURE DIRECT) to SP OUT ....................0.05% or less
Signal to Noise Ratio
(IHF-A network)
PHONO (MM) (PURE DIRECT) to SP OUT (Input 1k-ohm shorted)
...................................................................................95dB or more
AUDIO 2 etc. (PURE DIRECT) to SP OUT (Input 1k-ohm shorted)
.................................................................................110dB or more
Residual Noise
(IHF-A network)
SP OUT ...................................................................... 150 μ V or less
Channel Separation
(1 kHz/10 kHz)
PHONO (MM) (Input 1 k-ohm shorted)
.........................................................75dB or more / 60dB or more
AUDIO 2 etc. (Input 1 k-ohm shorted)
.........................................................75dB or more / 61dB or more
Volume Control Range/Step
Main Zone .......................... MUTE / -80dB to +16.5dB / 0.5dB step
Zone 2 (SP OUT) ................ MUTE / -80dB to +16.5dB / 0.5 dB step
Zone 2 (PRE OUT) (Digital Input Tone Control and ENHANCER OFF)
............................................. MUTE / -80dB to +10.0dB / 0.5 dB step
Tone Control Characteristics
Main Zone
Bass
Boost/Cut ...........................................± 6.0dB / 0.5dB step, at 50Hz
Turnover frequency ....................................................................350Hz
Treble
Boost/Cut ......................................... ± 6.0dB / 0.5dB step, at 20kHz
Turnover frequency ...................................................................3.5kHz
Zone 2
Bass
Boost/Cut ...........................................± 6.0dB / 0.5dB step, at 50Hz
Turnover frequency ....................................................................350Hz
Treble
Boost/Cut ......................................... ± 6.0dB / 0.5dB step, at 20kHz
Turnover frequency ...................................................................3.5kHz
Bass Crossover Frequency
Cut Off Frequency.... 40 / 60 / 80 / 90 / 100 / 110 / 120 / 160 / 200Hz
H.P.F (Front, Center, Surround, Surround Back SMALL) ....12dB/oct.
L.P.F (Subwoofer) ................................................................24dB/oct.
OPTICAL Jack, COAXIAL Jack Support Frequencies
OPTICAL .................................................................. 32kHz to 96kHz
COAXIAL ................................................................ 32kHz to 192kHz
n
FM Tuner Section
Tuning Range
U, C models ...................................................87.5MHz to 107.9MHz
R, L, V, P, S models
.......................... 87.5MHz to 108.0MHz / 87.50MHz to 108.00MHz
T, K, A, B, G, F models ...............................87.50MHz to 108.00MHz
50 dB Quieting Sensitivity
(IHF)
(1 kHz, 100 % MOD.)
Mono .........................................................................3 μ V (20.8dBf)
Signal to Noise Ratio
(IHF)
Mono .......................................................................................... 69dB
Stereo .........................................................................................68dB
Harmonic Distortion
(1 kHz)
Mono ........................................................................................... 0.5%
Stereo .......................................................................................... 0.6%
Antenna Input
...........................................................................75 ohms unbalanced
n
AM Tuner Section (U, C, R, T, K, L, V, P, S models)
Tuning Range
U, C models ............................................................. 530 to 1,710 kHz
R, L, V, P, S models .................... 530 to 1,710 kHz / 531 to 1,611 kHz
T, K models .............................................................. 531 to 1,611 kHz
Antenna Input
...................................................................................... Loop antenna
n
DAB
+
Tuner Section (A, B, G, F models)
Tuning Range
....................................................174.928 to 239.200 MHz (BAND III)
Support Audio Format
............................MPEG 1 Layer II/MPEG-4 HE-AAC v2 (aacPlus v2)
Antenna Input
...........................................................................75 ohms unbalanced
n
General
Power Supply
U, C models .............................................................. AC120 V, 60Hz
V, P, S models.....................................................AC 110–120V, 60Hz
T model ..................................................................... AC 220V, 50Hz
K model ..................................................................... AC 220V, 60Hz
A model ..................................................................... AC 240V, 50Hz
B, G, F models .......................................................... AC 230V, 50Hz
R, L models ...................................................AC 220–240V, 50/60Hz
Power Consumption
.................................................................................................. 410W
Standby Power Consumption
HDMI Control Off / Standby Through Off /
Network Standby Off .................................................................. 0.4W
HDMI Control On / Standby Through On /
Network Standby Off (INPUT: AV 1, HDMI no signal) ................ 1.9W
HDMI Control Off / Standby Through Off /
Network Standby On / Bluetooth Standby Off
(Wired) ..................................................................................... 1.7W
(Wi-Fi) ...................................................................................... 1.8W
HDMI Control Off / Standby Through Off /
Network Standby On (Wired) / Bluetooth Standby On............... 1.7W
HDMI Control On / Standby Through On /
Network Standby On (Wi-Fi) / Bluetooth Standby On ................ 3.0W
Maximum Power Consumption
(All ch driven, 10% THD)
R, L, P, S models ....................................................................... 980W
Dimensions (W
×
H
×
D)
................................ 435
×
191
×
442mm (17-1/8”
×
7-1/2”
×
17-3/8”)
Reference Dimension with wireless antenna upright
(W
×
H
×
D)
.............................. 435
×
270
×
442mm (17-1/8”
×
10-5/8”
×
17-3/8”)
Weight
................................................................................ 16.2kg (35.7lbs)
Accessories
Remote control ...............................................................................
×
1
FM antenna (1.4 m) (U, C, R, T, K, L, V, P, S models) ....................
×
1
DAB / FM antenna (1.6 m) (A, B, G, F models) .............................
×
1
AM antenna (1.0 m) (U, C, R, T, K, L, V, P, S models) ....................
×
1
YPAO microphone (6 m) ................................................................
×
1
Plate ...............................................................................................
×
1
Pole ................................................................................................
×
1
Antenna isolator (T model) .............................................................
×
1
Power cable
U, C, T, K, A, B, G, F, V, P, S models ............................................
×
1
R, L models .................................................................................
×
2
Battery (LR03, AAA, UM-4) ............................................................
×
2
* Specifications are subject to change without notice.
J ................... Japanese model
U ........................U.S.A. model
C ................. Canadian model
R .................... General model
T.....................Chinese model
K ......................Korean model
A .................Australian model
B .......................British model
G ................. European model
E .......South european model
F..................... Russian model
L................. Singapore model
V ...................... Taiwan model
P ........ Latin american model
S ...................Brazilian model
H ...........................Thai model
