5-20
Order Job/Part Q’ty Remarks
1
2
3
4
5
6
7
Removing the valves and valve
springs
Cylinder heads
Rocker arms and camshafts
Valve cotter
Valve spring retainer
Valve spring
Valve (intake)
Valve (exhaust)
Valve stem seal
Valve spring seat
4
2
2
1
1
2
2
Remove the parts in the order listed.
Refer to “CYLINDER HEADS”.
Refer to “ROCKER ARMS AND
CAMSHAFTS”.
Refer to “REMOVING/INSTALLING
THE VALVES”.
For installation, reverse the removal
procedure.
Refer to “INSTALLING THE VALVES”.
VALVES AND VALVE SPRINGS
ENG
VALVES AND VALVE SPRINGS
