Yamaha XVS250 2001 - Electrical Specifications

2-12
ELECTRICAL SPECIFICATIONS
SPEC
ELECTRICAL SPECIFICATIONS
Item Standard Limit
System voltage 12 V
DDD
Ignition system
Ignition system type
Ignition timing
Advancer type
Pickup coil resistance/color
Transistorized coil ignition unit model
(manufacturer)
TCI
8_ BTDC at 1,300 r/min
Digital
192  288 Ω/L/Y – G/W
TNDF62 (DENSO)
DDD
DDD
DDD
DDD
DDD
Ignition coils
Model (manufacturer)
Minimum ignition spark gap
Primary coil resistance
Secondary coil resistance
J0226, J0227 (DENSO)
6 mm
3.4  4.6 Ω
10.4  15.6 kΩ
DDD
DDD
DDD
DDD
Throttle position sensor standard
resistance
4.0  6.0 kΩ
DDD
Charging system
System type
Model (manufacturer)
Nominal output
Stater coil resistance/color
AC magneto
TLMX21 (DENSO)
14 V/23 A at 5000 r/min
0.224  0.336 Ω at 20_C/W-W
DDD
DDD
DDD
DDD
Voltage regulator
Regulator type
Model (manufacturer)
No-load regulated voltage
Semiconductor, short circuit
SH650D-11 (SHINDENGEN)
14.1  14.9 V
DDD
DDD
DDD
Rectifier
Model
Rectifier capacity
Withstand voltage
SH650D-11/SHINDENGEN
18 A
200 V
DDD
DDD
DDD
Battery
Battery type
Battery voltage/capacity
GT6B-3
12 V 6 Ah
DDD
DDD
Headlight type Halogen bulb
Bulbs (voltage/wattage  quantity)
Headlight
Auxiliary light
Tail/brake light
Turn signal light
12 V 60 W/55 W  1
12 V 4 W  1
12 V 5 W/21 W  1
12 V 21 W  4
DDD
DDD
DDD
DDD
