3-5
FUEL TANK AND AIR FILTER
CHK
ADJ
NOTE:
NOTE:
REMOVAL
1. Remove:
S Ignitor plate
To remove the quick fastener, push its center in
with a screwdriver, then pull the fastener out.
INSTALLATION
1. Install:
S Ignitor plate
To install the quick fastener, push its pin so that it
protrudes from the fastener head, then insert
the fastener into the cowling and push the pin
a
in with a screwdriver. Make sure that the pin is
flush with the fastener’s head.
