Yamaha XVS250 2001 - Checking the Air Induction System

6-19
AIR INDUCTION SYSTEM
CARB
CHECKING THE AIR INDUCTION SYSTEM
1. Check:
 hoses
1
Loose connection  Connect properly.
Cracks/damage
 Replace.
 pipes
2
Cracks/damage  Replace.
2. Check:
 air filter element
1
Damage  Replace.
3. Clean:
 air filter element
Apply compressed air to the inner surface of
the air filter element.
4. Check:
 fiber reed
1
 fiber reed stopper
 reed valve seat
Cracks/damage
 Replace the reed valve.
